High Speed Horizontal Machining Center YSHD-1250D CNC Control System

High Speed Horizontal Machining Center YSHD-1250D CNC Control System

Compared to vertical machining centers, horizontal machining centers offer the potential for improved spindle uptime, cycle times and throughput. Although they come with a higher price tag, their higher productivity can be significant to shops of all sizes.





  • Max. X-axis Travel :

    2000mm
  • Max. Y-axis Travel :

    1350mm
  • Max. Z-axis Travel :

    1350mm
  • Max Workpiece Length :

    1250mm
  • Max Workpieces Width :

    1250mm
  • Max Workpieces Weight :

    5.0T
  • Application :

    Precision Mold, Bathroom Products, Auto Parts
  • Processing :

    Drilling, Tapping

Machine Cutting Performance

Surface Milling

Steel 45#

Drilling Holes

Steel 45#

Tapping

Steel 45#

Cutting depth

7mm



Cutter diameter

Ø82

Tapping

M36

Cutter

Ø120mm*5T

Cutter

Ø82mm*2T

Cutter

M36*3P

Spindle speed

420rpm

Spindle speed

500rpm

Spindle speed

120rpm

Feed

F500

Feed

F100

Feed

F480

Width

100mm

Width

82mm

Width

36mm



Horizontal Machining Product Characteristics

Machine Bed, Column

Equilateral triangle structure of the column, multi-layer stiffeners are arranged to improve the stability of the machine bed.

Positive T structure bed, X-axis stepped layout, enlarged line guideway span, rigid support.

Adopt a high-strength Rexroth roller guide, high load bearing, and stable precision.

Spindle

install 6 high-rigidity bearings;

Outer diameter 190mm Taiwan original BBT50 spindle;

Spindle air blow to prevent objects from entering the spindle;

The spindle is equipped with ring spray to improve processing quality. The standard FANUC large-torque-wide-area motor ilP30/8000 is equipped with stronger heavy-cutting ability.

Optical Linear Scales

Optional Heidenhain, Fagor Optical Linear Scales, accuracy ± 5um, to ensure machine tool positioning accuracy.

Double exchange table/ four-axis turntable

Realize workpiece exchange and improve processing efficiency;

The workpiece is placed outside for easy clamping;

High rigidity alloy turbine, wear-resistant, high positioning accuracy;

Heavy locking, reduces deformation, resistant to heavy cutting.

Tool magazine

Using Taiwan imported frequency conversion tool magazine, tool change speed is fast and stable.



Horizontal Machining Center Parameters

Model YSHD-1250D
Subject Specifications Units
Travel X/Y/Z axis mm 2000/1350/1350
Spindle Nose to Worktable mm 50-1400
Spindle Center to Column mm 350-1700
Three-Axis Guideway   Roller Linear Guideway
Worktable Worktable Size (L*W) mm 1250*1250
Maximum Table Load t 5
Table Screw mm
T-Slot mm 7-22x160
Number of Pallet pcs 2
Table Indexing   1°/0.001°
Maximum Turning Diameter mm φ2200
Spindle Spindle Taper type BBT-50
Spindle Speed rpm 6000
Spindle Drive Type   Belt
Feedrate Rapid Traverse(X/Y/Z) m/min 10/10/10
Cutting Feedrate(X/Y/Z) m/min 10
Tool Changer Automatic Tool Changer   ARM Type (Servo Drive)
Type of Tool Shank type BT-50
Tool Storage Capacity Piece 24
Max. Tool Diameter (Adjacent) mm 125
Max. Tool Diameter (Empty) mm 250
Max. Tool Length mm 500
Max. Tool Weight kg 25
Tool Change Time sec 4.9
Motor Spindle Motor kw 15/18.5
Three-Axis Servo Motor kw 3.0/3.0/3.0
Accuracy Accuracy mm ±0.01
Repeatability mm ±0.005
Power Required Power Requirement kva 45
Air Pressure Requirement kg/cm² 6^8
Others External Dimensions (L*W*H) mm 10308*6095*4100
Gross Weight t 31

Standard Accessories
Arm Type Tool Changer
Automatic Lubricating System
Fully Enclosure Guard
Rigid Tapping
Heat Exchange for Electric Cabinet
Coolant Tank & Chip Tray
Daul LED Work Light
LED 3 Color Warning Light
M30 Auto Off
Spindle Nose Air Blow
Leveling Bolts and Pads


Options
Optical Linear Scale
CTS
Tool Breakage System
Chain Type Chip Conveyor System
Oil Mist Collector
Oil Skimmer
Rotary Table
Workpiece &Tool Probe
