Horizontal Boring Machining Center with Good Service YSBD-130/15T

Horizontal Boring Machining Center with Good Service YSBD-130/15T

Horizontalboring machine is provided with a large working table for heavy loading capacity. Generous dimensioning of the hydraulic clamping system enables the capacity for heavy cutting. Super rigid & compact Spindle headstock with cooling & lubrication oil supplied to all the thermal sources in the Spindle head to minimize its thermal expense.

  • Max. X-axis Travel :

    3000mm
  • Max. Y-axis Travel :

    2600mm
  • Max. Z-axis Travel :

    1500mm
  • Max Workpiece Length :

    1800mm
  • Max Workpieces Width :

    2200mm
  • Max Workpieces Weight :

    15T
  • Application :

    Auto Parts
  • Processing :

    Surface Milling, Drilling Holes, Tapping

Horizontal Boring Machining Center Structure Characteristics

1. Tool magazine structure

40 and 60 tools guideway-type tool magazines, which are driven by a servo tool magazine, improve the overall tool change efficiency.

2. Spindle structure

The main shaft installs European structure design, high rigidity, high speed, and low vibration. Low speed and high torque for the spindle.

3. The worktable installs super-large grinding gears. It is combined with twin-turbo, vortex anti-backlash structure to ensure accuracy.

4. Transmission structure

The X and Z-axis transmission method installs a direct-acting four-wheel drive. It has stable accuracy. Also, it could eliminate backlash, and improve torsional rigidity and allow angle. The Y-axis installs direct-drive transmission and cooperates with a German reducer to improve torsional rigidity.

5. Counterweight structure

Use servo frequency conversion hydraulic station, the counterweight of the hydraulic cylinder reduces the axial load and lengthen the life.

6. Casting structure design

The linear guideway installation surface and the ballscrew center are on the same plane, which makes the ballscrew drive more stable and ensures the stability of the overall accuracy of the machine tool.

7. Hanging guideway structure

The Y-axis adopts a box-in-box high-rigidity right and left paired lining structure. The Y-axis installs 4 linear guide guideways, 2 front and 2 back, with high rigidity, high precision, and long service life.





Parameters

Model

YSBD-130/15T

Subject

Specifications

Units



Travel

X-Axis (Standard)

mm

3000

X-Axis (Optional)

mm

  3500/4500/5500

Y-Axis (Standard)

mm

2600

Y-Axis (Optional)

mm

3200

Z-Axis (Standard)

mm

1500

Z-Axis (Optional)

mm

2000

W-Axis (Standard)

mm

700

Worktable

Worktable Size-standard (L*W)

mm

1800x2200/15T

Worktable Size -Option (L*W)

mm

2500x2500/20T

Table Indexing

deg

0.001°

T-Slot

mm

24H7x 200x7

Spindle

Spindle Nose to Worktable

mm

75~2675

Spindle Nose to Table Center

mm

60~2260

Spindle Diameter

mm

130

Spindle Type

/

BT50

Spindle R.P.M.

rpm

3000

Spindle Transmission

/

Belt

Motor

Spindle Motor

kw

22/30

Maximum Torque

Nm

3011/4108.5

Accuracy

Indexing Accuracy

arc/sec

10"

Indexing Repeatability

arc/sec

±4"

Position Accuracy

mm

0.01

Repeatability

mm

0.005



Drive Type



X/Y/Z- Axis

/

Direct

W-Axis

/

Belt

Feedrate

X/Y/Z/W Cuttinq Feedrate

m/min

10/10/10/5

X/Y/Z/W Rapid Traverse

m/min

10/10/10/8

Tool Changer

Rod Storage Capacity

/

60

Selecton Method

/

Servo Drive

Max. Tool Diameter

kg

25

Max. Tool Weight

mm

500

Max. Tool Length

mm

125/250

Tool Change Time

sec

14

Power Required

Air Pressure Requirement

kg/c

6

Power Requirement

kva

95

Others

External Dimensions (L*W*H)

mm

8000X7500X5500

Gross Weight

t

45



Standard Accessories

ARM Type Tool Changer Rigid Tapping Dual LED Work Light Spindle Nose Air Blow
Automatic Lubricating System Heat Exchange for Electric Cabinet LED 3 Color Warning Light Leveling Bolts and Pads
Semi-Endosed Guard Coolant Tank & Chip Tray M30 Auto Off Rotary Table



Options

Optical Linear Scale Tool Breakage System Oil Mist Collector Workpiece & Tool Probe
CTS Chip Conveyor System Oil Skimmer Auto Parts Probe Measuring System
