Vertical gantry cradle 5 Axis machining center adopts U The type base is combined with the bridge-type upper structure into a complete box structure, forming a fully enclosed force flow circuit, so the structure has high rigidity and strong stability. The symmetrical structure makes the thermal deformation error small, the three-axis drive is close to the center of gravity, the motion responsiveness and synchronization are excellent, the machine tool processing accuracy , finish are high, and the stability is strong;
Vertical machining centres can cut a wide variety of materials, lower production cycle times, reduce the cost of machining and increase the profitability of the process. The machine has been developed with great hindsight from the engineers to reduce the downtimes associated with frequent quality checks. CNC vertical machine is ergonomically designed in order to achieve enhanced operating conditions.
X/Z axis 6 sliding seat support, strong rigidity
Can process 8 parts at the same time with 8 electric spindles which maximum speed is 18000rpm
Column double-arm structure design
NSK original bearing (3062), 3+2 mode, pre-tensioning treatment to prevent thermal change bit
Stable, high-speeed & high-precision Mitsubish M80 system
