Gantry Large Double Column Machining Center YSM-7032

Gantry Large Double Column Machining Center YSM-7032

High-Precision Gantry Machining Center Double-Column Heavy-Duty Turning/Milling/Grinding/Cutting/Drilling Hardware Machining Center

  • Max. X-axis Travel :

    7000mm
  • Max. Y-axis Travel :

    3200mm
  • Max. Z-axis Travel :

    1000mm
  • Max Workpiece Length :

    6400mm
  • Max Workpieces Width :

    2600mm
  • Max Workpieces Weight :

    25T
  • Application :

    Medical Industry
  • Processing :

    Drilling, Tapping, Milling, Surface Milling

Square-Type Ram Gantry CNC Machine Structure Characteristics

The square ram series gantry vertical machining center, on the basis of inheriting the advantages of the traditional gantry machine tool base frame with strong rigidity, symmetrical structure and strong stability, introduces the dynamic rigid design concept and optimizes the design of the moving parts. The machine tool has large torque and good response characteristics, which is suitable for the needs of various machining fields.









① Square ram structure 500X500MM

The machine installs a four-sided restraint quenching guide guideway and double-cylinder nitrogen balance device. The overall rigidity is strong. It has the strong cutting ability and stable precision.



② Italy BF gearbox

High-performance speed, low noise, expandable motor constant power range with easy installation. It can be used in conjunction with multiple series of motors and adapt to high-strength tension.



③ Fully automatic side milling head

The transmission gear is a Gleason spiral bevel gear. The transmission is stable and accurate. It has a long service life. The internal transmission key of the milling head is a quenched part with minimal backlash.



Double-Column Machining Center Parameters

Model YSM-7032
Subject Specifications Units
Travel X-Axis mm 7000
Y-Axis mm 3200
Z-Axis mm 1000 (Optional 1250/1500)
Spindle Nose to Worktable mm 350-1350
Three-Axis Guideway   X/Y Heavy Load Roller Linear Guideway Z-Axis Square-Type Ram
Door Width   3200
Type of Ram   Square-Type Ram (500x500)
Worktable Worktable Size(L*W) mm 6400*2600
Maximum Table Load t 25
T-Slot mm 13-28*200
Spindle Spindle Type type BBT-50
Spindle R.P.M. rpm 6000
Spindle Drive Type   DDS
Feedrate Rapid Traverse (X/Y/Z) m/min 6/10/10
Cutting Feedrate (X/Y/Z) m/min 6
Tool Changer ATC   24 (Option: 40/60)
Motor Spindle Motor KW 22/26 (140-286 Nm)
Three-Axis Servo Motor KW 6/3/3 (38/36/36 Nm)
Accuracy Accuracy mm 0.045/0.025/0.015
Repeatability mm 0.03/0.02/0.01
Power Required Power Requirement kva 55
Air Pressure Requirement kg/cm² 6^8
Others External Dimensions (L*W*H) mm 15600*6450*5820(6320)
Gross Weight t 66



Standard Accessories

Spindle Coolant System

Automatic Lubricating System

Semi-Enclosed Guard

Rigid Tapping

Heat Exchange for Electric Cabinet

Dual-Screw Type Chip Conveyor

Dual LED Work Light

LED 3 Color Warning Light

Chain Type Chip Conveyor and Cart

Geared Box

Leveling Bolts and Pads

M30 Auto Off



Options

Optical Linear Scale

CTS

20T/40T/60T ATC

Workpieces Probe

Chip Conveyor System

Rotary Table

Oil Mist System

Oil Skimmer

Manual/Semi-Auto 90Milling Head

Auto Parts Probe Measuring System
