Double Column Gantry CNC Machine With Moving Column YSMD-16042

Double Column Gantry CNC Machine With Moving Column YSMD-16042

The moving-column gantry machining center has the advantages of high worktable load, improved plant space utilization, modular oversized specifications, convenient loading and unloading, and improved tool change efficiency.

  • Max. X-axis Travel :

    16000mm
  • Max. Y-axis Travel :

    4200mm
  • Max. Z-axis Travel :

    1500mm
  • Max Workpiece Length :

    16000mm
  • Max Workpieces Width :

    3500mm
  • Max Workpieces Weight :

    50T
  • Application :

    Medical Industry
  • Processing :

    Drilling, Tapping, Milling, Surface Milling

Double Column Machining Center

The moving-column gantry machining center has the advantages of high worktable load, improved plant space utilization, modular oversized specifications, convenient loading and unloading, and improved tool change efficiency. The working table of the moving column gantry machining center is fixed and does not participate in the movement of the X and Y axes. Therefore, the floor space of the machine tool is greatly reduced and the utilization rate of the customer's workshop is improved.

  • ①. Dual Motor with Anti-Backlash Transmission Structure

    High Precision, Heavy Load, High Speed, Low Noise, Longer Service Life.

    ②. Gear Transmission

    High Precision, Heavy Load, High Speed, Low Noise, Longer Service Life.

    ③. Square Ram and Sliding Seat Structure

    Dimension:500x500, Heavy-Duty Design;

    Direct-Driven Design;

    Large-Size and Heavy-Duty design ensures that the ram is firmly connected;

    Three extended sliders at the top and four standard sliders at the bottom.

    ④. Vertical / Horizontal Automatic Tool Magazine

    ⑤. Italy BF Gear Box

    High-performance speed, low noise. It could expand the motor's constant power range. It is easy to install. The machine can be used in conjunction with multiple series of motors. It can adapt to high-strength tension and small size.

    ⑥. Extended Angle Milling Head

    ⑦. Automatic Hydraulic Angle Milling Head

    ⑧. Two-Way Spindle Angle Milling Head

Moving Column Series Parameters

Model

YSMD-16042

Subject

Specifications

Units



Travel

X-Axis

mm

16000

Y-Axis

mm

4200

Z-Axis

mm

1500

Spindle Nose to Worktable

mm

350-1850

Three-Axis Guideway



X/Y Heavy Load Roller Linear Guideway Z-Axis Square-Type Ram

Door Width



4200

Type of Ram



Square-Type Ram (500 * 500)

Worktable

Worktable Size(L*W)

mm

16000*3500

Maximum Table Load

t

50

T-Slot

mm

36*200

Spindle

Spindle Type

type

BBT-50

Spindle R.P.M.

rpm

6000

Spindle Drive Type



DDS

Feedrate

Rapid Traverse (X/Y/Z)

m/min

6/8/8

Cutting Feedrate (X/Y/Z)

m/min

6

Tool Changer

ATC



24 (Option: 40/60)

Motor

Spindle Motor

KW

17-42

Three-Axis Servo Motor

KW

5.2/5.2/5.2

Accuracy

Accuracy

mm

0.08/0.035/0.02

Repeatability

mm

0.065/0.025/0.015

Power Required

Power Requirement

kva

60

Air Pressure Requirement

kg/cm²

6^8

Others

External Dimensions (L*W*H)

mm

20000x5860x5800

Gross Weight

t

145



Standard Accessories

Spindle Coolant System

Automatic Lubricating System

Semi-Enclosed Guard

Rigid Tapping

Heat Exchange for Electric Cabinet

Dual-Screw Type Chip Conveyor

Dual LED Work Light

LED 3 Color Warning Light

Chain Type Chip Conveyor and Cart

Geared Box

Leveling Bolts and Pads

M30 Auto Off



Options

Optical Linear Scale

CTS

20T/40T/60T ATC

Workpieces Probe

Chip Conveyor System

Rotary Table

Oil Mist System

Oil Skimmer

Manual/Semi-Auto 90Milling Head

Auto Parts Probe Measuring System
